TPS2041BDBVR Texas Instrument Electronic Components
  • TPS2041BDBVR Texas Instrument Electronic ComponentsTPS2041BDBVR Texas Instrument Electronic Components

TPS2041BDBVR Texas Instrument Electronic Components

Kinglionski is the agent and distributor of TPS2041BDBVR Texas Instrument Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

With years of experience in production TPS2041BDBVR Texas Instrument Electronic Components, Kinglionski can supply a wide range of TPS2041BDBVR Texas Instrument Electronic Components. TPS2041BDBVR  belongs to  0.5A loading, ±25% ILIMIT accuracy, 2.7-5.5V, 70mΩ USB power switch, active-low of Texas Instruments(TI).The TPS20xxB are current-limited, power-distribution switches providing 0.5-A continuous load current. These devices incorporates 70-mΩ N-channel MOSFET power switches for power-distribution systems that require multiple power switches in a single package. Gate driver is provided by an internal charge pump designed to minimize current surges during switching. The charge pump requires no external components and allows operation supplies as low as 2.7 V.

The TPS20xxB power-distribution switches are intended for applications where heavy capacitive loads and short circuits are likely to be encountered. These devices incorporates 70-mΩ N-channel MOSFET power switches for power-distribution systems that require multiple power switches in a single package. Each switch is controlled by a logic enable input.


When the output load exceeds the current-limit threshold or a short is present, the device limits the output current to a safe level by switching into a constant-current mode, pulling the overcurrent (OCx) logic output low. When continuous heavy overloads and short circuits increase the power dissipation in the switch, causing the junction temperature to rise, a thermal protection circuit shuts off the switch to prevent damage. Recovery from a thermal shutdown is automatic once the device has cooled sufficiently. Internal circuitry ensures that the switch remains off until valid input voltage is present. This powerdistribution switch is designed to set current limit at 1 A (typical).

Product Features

Type

Main product features

TPS2041BDBVR



70-mΩHigh-Side MOSFET

500-mA Continuous Current

Thermal and Short-Circuit Protection

Operating Range: 2.7 V to 5.5 V


Product Application

Heavy Capacitive Loads
Short-Circuit Protections
