ADG1421BRMZ-REEL7 Devices Electronic

Kinglionski is the agent and distributor of Analog Devices electronic model ADG1421BRMZ-REEL7 Devices Electronic, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The ADG1421BRMZ-REEL7 Devices Electronic contain two i/ndependent single-pole/single-throw (SPST) switches.The ADG1421 and ADG1422 differ only in that the digital control logic is inverted. The ADG1421 switches are turned on with Logic 1 on the appropriate control input, and Logic 0 is required for the ADG1422.

The on resistance profile is very flat over the full analog input

range ensuring excellent linearity and low distortion when

switching audio signals. The iCMOS construction ensures

ultralow power dissipation, making the part ideally suited for

portable and battery-powered instruments.

Product Features

Type	Main product features
ADG1421BRMZ-REEL7	2.1 Ω on resistance
	0.5 Ω maximum on resistance flatness
	Up to 250 mA continuous current
	Fully specified at +12 V, ±15 V, ±5 V
