ADS8568SPMR Electronic Components

The ADS8568SPMR Electronic Components series includes eight 12-, 14-, and 16-bit analog-to-digital converters (ADCs) that operate based on the successive approximation register (SAR) architecture. This architecture is designed on the charge redistribution principle that inherently includes a sample-and-hold function.

The eight analog inputs are grouped into four channel pairs. These channel pairs can be sampled and converted simultaneously, preserving the relative phase information of the signals of each pair. Separate conversion start signals allow simultaneous sampling on each channel pair of four, six, or eight channels.

The ADS85x8 contain eight low-power, 12-, 14-, or 16-bit, successive approximation register (SAR)- based analog-to-digital converters (ADCs) with true bipolar inputs. These channels are grouped in four pairs, thus allowing simultaneous high-speed signal acquisition of up to 650 kSPS.

Product Features

Product Applications

Protection Relays

Power Quality Measurement

Multi-Axis Motor Controls

Programmable Logic Controllers

Industrial Data Acquisition
