ATTINY10-TSHR Devices Electronic

Product Description

Buy Hot Sale ATTINY10-TSHR Devices Electronic made in China. The Atmel® ATtiny4/5/9/10 is a low-power CMOS 8-bit microcontroller based on the AVR® enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATtiny4/5/9/10 achieves throughputs close to 1 MIPS per MHz. This empowers system designer to optimize the device for power consumption versus processing speed.

Product Features

High Performance, Low Power AVR® 8-Bit Microcontroller

Advanced RISC Architecture

–54 Powerful Instructions

–Most Single Clock Cycle Execution

–16 x 8 General Purpose Working Registers

 Non-volatile Program and Data Memories

–512/1024 Bytes of In-System Programmable Flash Program

Memory

–32 Bytes Internal SRAM

–Flash Write/Erase Cycles: 10,000

–Data Retention: 20 Years at 85°C / 100 Years at 25°C

 Peripheral Features

–QTouch® Library Support for Capacitive Touch Sensing (1Channel)

–One 16-bit Timer/Counter with Prescaler and Two PWM Channels

–Programmable Watchdog Timer with Separate On-chip Oscillator

Special Microcontroller Features

–In-System Programmable (at 5V, only)

–External and Internal Interrupt Sources

–Low Power Idle, ADC Noise Reduction, and Power-down Modes

I/O and Packages

–Four Programmable I/O Lines

–6-pin SOT and 8-pad UDFN

 Operating Voltage:

–1.8 - 5.5V

Programming Voltage:–5V

Speed Grade:

–0 - 4 MHz @ 1.8 - 5.5V

–0 - 8 MHz @ 2.7 - 5.5V

–0 - 12 MHz @ 4.5 - 5.5V

Industrial and Extended Temperature Ranges

Low Power Consumption

–Active Mode: 200μA at 1MHz and 1.8V

Idle Mode:25μA at 1MHz and 1.8V

–Power-down Mode: <0.1μA at 1.8V
