BQ76PL455ATPFCRQ1 Texas Instrument Electronic Components

BQ76PL455ATPFCRQ1  belongs to 16-cell battery monitor with passive cell balancing of Texas Instruments.The bq76PL455A-Q1 is an integrated 16-cell monitor, protector, and cell balancer designed for high-reliability automotive applications with many built-in self-diagnostic features.

The bq76PL455A-Q1 device is an integrated 16-cell battery monitoring and protection device, designed for high-reliability automotive applications.The bq76PL455A-Q1 monitors and detects several different fault conditions, including: overvoltage, undervoltage, overtemperature, and communication faults. Six GPIO ports as well as eight analog AUX ADC inputs are included for additional monitoring and programmable functionality. A secondary thermal shutdown is included for further protection.

BQ76PL455ATPFCRQ1 Texas Instrument Electronic Components Features

Type	Main product features
BQ76PL455ATPFCRQ1	Monitors and Balances 6-to-16 Cells per Device
	Highly Accurate Monitoring
	Engineered for High System Robustness
	Passive Balancing with External n-FETs and Active Balancing with EMB1428Q/EMB1499Q

Product Applications

Electric and Hybrid Electric Vehicles
48-V Systems
Energy Storage (ESS) and UPS
E-Bikes, E-Scooters
