DS90UB954TRGZTQ1 Electronic Components
  • DS90UB954TRGZTQ1 Electronic ComponentsDS90UB954TRGZTQ1 Electronic Components

DS90UB954TRGZTQ1 Electronic Components

Kinglionski is the agent and distributor of Texas Instruments model DS90UB954TRGZTQ1 Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The DS90UB954TRGZTQ1 Electronic Components is a versatile deserializer that aggregates up to two inputs acquired from a FPD-Link III stream and transmits the received data over a MIPI camera serial interface (CSI-2). When coupled with an ADAS FPD-Link III serializer (DS90UB953-Q1, DS90UB935-Q1, DS90UB933-Q1 or DS90UB913A-Q1), the DS90UB954-Q1 receives data streams from multiple sensors to be multiplexed on the same CSI-2 links. When paired with the DS90UB953-Q1 or the DS90UB935-Q1, the DS90UB954-Q1 operates at full features, and in backwards compatible mode with DS90UB933-Q1 serializer or DS90UB913A-Q1, operates with basic functionality.


The DS90UB954-Q1 is a versatile dual deserializer hub capable of receiving serialized sensor data from one or two independent sources through an FPD-Link III interface. When paired with a DS90UB953-Q1 serializer, the DS90UB954-Q1 receives data from imagers, supporting 2MP/60fps and 4MP/30fps cameras as well as satellite RADAR and other sensors such as ToF and LIDAR.


DS90UB954TRGZTQ1 Electronic Components Features

Type

Main product features

DS90UB954TRGZTQ1

AEC-Q100 Qualified for Automotive Applications – Device Temperature Grade 2: –40℃to +105℃Ambient Operating Temperature Range

Dual Deserializer Hub Aggregates One or Two Active Sensors Over FPD-Link III Interface

Power-Over-Coax (PoC) Compatible Transceiver

Ultra-Low Data and Control Path Latency


Product Applications

Automotive ADAS

– Rear View Cameras (RVC)

– Surround View Systems (SVS)

– Camera Monitor Systems (CMS)

– Forward Vision Cameras (FC)

– Driver Monitoring Systems (DMS)

– Satellite RADAR, Time of Flight (ToF) and LIDAR Sensor Modules

Security and Surveillance

Industrial and Medical Imaging
