LAN9252I PT Devices Electronic

The LAN9252I PT Devices Electronic is a 2/3-port EtherCAT slave controller with dual integrated Ethernet PHYs which each contain a fullduplex 100BASE-TX transceiver and support 100Mbps (100BASE-TX) operation. The LAN9252 supports HP AutoMDIX, allowing the use of direct connect or cross-over LAN cables. 100BASE-FX is supported via an external fiber transceiver.

The LAN9252 includes an EtherCAT slave controller with 4K bytes of Dual Port memory (DPRAM) and 3 Fieldbus Memory Management Units (FMMUs).

Highlights

2/3-port EtherCAT slave controller with 3 Fieldbus Memory Management Units (FMMUs) and 4 SyncManagers
Interfaces to most 8/16-bit embedded controllers and 32-bit embedded controllers with an 8/16-bit bus
Integrated Ethernet PHYs with HP Auto-MDIX
Wake on LAN (WoL) support
Low power mode allows systems to enter sleep mode until addressed by the Master
Cable diagnostic support
1.8V to 3.3V variable voltage I/O
Integrated 1.2V regulator for single 3.3V operation
Low pin count and small body size package

Target Applications

Motor Motion Control
Process/Factory Automation
Communication Modules, Interface Cards
Sensors
Hydraulic & Pneumatic Valve Systems
Operator Interfaces

Key Benefits

Integrated high-performance 100Mbps Ethernet transceivers
- Compliant with IEEE 802.3/802.3u (Fast Ethernet)
- 100BASE-FX support via external fiber transceiver
- Loop-back modes
- Automatic polarity detection and correction
- HP Auto-MDIX
EtherCAT slave controller
- Supports 3 FMMUs
- Supports 4 SyncManagers
- Distributed clock support allows synchronization with other EtherCAT devices
- 4K bytes of DPRAM
8/16-Bit Host Bus Interface
- Indexed register or multiplexed bus
- Allows local host to enter sleep mode until addressed by EtherCAT Master - SPI / Quad SPI support
Digital I/O Mode for optimized system cost
3rd port for flexible network configurations
Packaging
- Pb-free RoHS compliant 64-pin QFN or 64-pin TQFPEP
Available in commercial, industrial, and extended industrial* temp. ranges
