LM3553SDXNOPB Texas Instrument Electronic Components
  • LM3553SDXNOPB Texas Instrument Electronic ComponentsLM3553SDXNOPB Texas Instrument Electronic Components

LM3553SDXNOPB Texas Instrument Electronic Components

Kinglionski is the agent and distributor of LM3553SDXNOPB Texas Instrument Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

Low Price Quality LM3553SDXNOPB Texas Instrument Electronic Components In Stock. LM3553SDXNOPB 1.2A dual flash LED driver System with I2C compatible interface belongs to of Texas Instruments(TI).The LM3553 is designed to use a 2.2µH inductor. When the device is boosting (VOUT > VIN) the inductor is one of the biggest sources of efficiency loss in the circuit.


Therefore, choosing an inductor with the lowest possible series resistance is important. Additionally, the saturation rating of the inductor should be greater than the maximum operating peak current of the LM3553. This prevents excess efficiency loss that can occur with inductors that operate in saturation and prevents over heating of the inductor and possible damage.


The LM3553 is a fixed frequency, current mode step-up DC/DC converter with two regulated current sinks.The device is capable of driving loads up to 1.2A from a single-cell Li-Ion battery.


The LM3553 includes a TX pin that forces Torchmode during a flash event allowing for synchronization between the RF power amplifier andFlash/Torch modes. It also includes a multi-function pin (M/F) that can serve as a GPIO and a hardware RESET pin. The LM3553 is available in a 3mm by 3mm package.

Product Features

Type

Main product features

LM3553SDXNOPB



Accurate and Programmable LED Current up to 1.2A in 128 Steps

Total Solution Size < 30mm2

90% Peak Efficiency

Active Low Hardware Reset


Product Application

Camera Phone LED Flash
Smartphone and PDA Flash
LED Backlight
