LPC1788FBD144 Electronic Components
  • LPC1788FBD144 Electronic ComponentsLPC1788FBD144 Electronic Components

LPC1788FBD144 Electronic Components

LPC1788FBD144 Electronic Components belongs to Scalable Mainstream 32-bit Microcontroller (MCU) based on Arm® Cortex®-M3 Core of NXP. The LPC1788FBD144 is an ARM Cortex-M3 based microcontroller for embedded applications requiring a high level of integration and low power dissipation. The ARM Cortex-M3 is a next generation core that offers better performance than the ARM7 at the same clock rate and other system enhancements such as modernized debug features and a higher level of support block integration. The ARM Cortex-M3 CPUincorporates a 3-stage pipeline and has a Harvard architecture with separate localinstruction and data buses, as well as a third bus with slightly lower performance for peripherals.

Send Inquiry

Product Description

Kinglionski is a professional China LPC1788FBD144 Electronic Components supplier, if you are looking for the best LPC1788FBD144 with low price, consult us now!Features include 512 kB of flash memory, 96 kB of data memory, Ethernet, USB 2.0 Host/OTG/Device , 8-channel DMA controller, 5 UARTs, 2 CAN channels, 3 SSP/SPI, 3 I2C, I2S, 8-channel 12-bit ADC, 10-bit DAC, QEI, LCD controller, SD/MMC interface, motor control PWM, 4 general purpose timers, 6-output general purpose PWM, ultra-low power Real-Time Clock with separate battery supply, and up to 109 general purpose I/O pins.

The LPC1788FBD144 is a Cortex-M3 microcontroller for embedded applications featuring a high level of integration and low power consumption at frequencies of 120 MHz.

LPC1788FBD144 Electronic Components Parameter (Specification)

Functional replacement for LPC23xx and 24xx family devices
Arm Cortex-M3 processor, running at frequencies of up to 120 MHz
Arm Cortex-M3 built-in Nested Vectored Interrupt Controller (NVIC)
Multilayer AHB matrix interconnect provides a separate bus for each AHB leader
Split APB bus allows for higher throughput
Cortex-M3 system tick timer, including an external clock input option

Standard JTAG test/debug interface, Serial Wire Debug and Serial WireTrace Port
Emulation trace module supports real-time trace
Boundary scan for simplified board testing
Non-maskable Interrupt (NMI) input
512 kB on-chip flash program memory
96 kB on-chip SRAM
4 kB on-chip EEPROM

In-System Programming (ISP) and In-Application Programming (IAP) capabilities
LCD controller, supporting both STN and TFT displays
External Memory Controller (EMC)
Eight channel General Purpose DMA controller (GPDMA)
Ethernet MAC with MII/RMII interface and associated DMA controller
USB 2.0 full-speed dual port device/host/OTG controller with on-chip PHY and DMA
Five UARTs with fractional baud rate generation
Three SSP controllers with FIFO and multi-protocol capabilities

Three enhanced I2C-bus interfaces
I2S (Inter-IC Sound) interface for digital audio input or output
CAN controller with two channels
SD/MMC memory card interface
Up to 109 General Purpose I/O (GPIO) pins
Two external interrupt inputs configurable as edge/level sensitive
Four general purpose timers/counters

Quadrature encoder interface that can monitor one external quadrature encoder
Two standard PWM/timer blocks with external count input option
Real-Time Clock (RTC) with a separate power domain
Windowed Watchdog Timer (WWDT)
12-bit Analog-to-Digital Converter (ADC) with conversion rates up to 400 kHz
10-bit Digital-to-Analog Converter (DAC)
Four reduced power modes: Sleep, Deep-sleep, Power-down, and Deep power-down

Wake-up Interrupt Controller (WIC)
Processor wake-up from Power-down mode via any interrupt
Brownout detect with separate threshold for interrupt and forced reset
On-chip Power-On Reset (POR)
On-chip crystal oscillator with an operating range of 1 MHz to 25 MHz
12 MHz Internal RC oscillator (IRC) trimmed to 1% accuracy
Unique device serial number for identification purposes
Single 3.3 V power supply (2.4 V to 3.6 V)

LPC1788FBD144 Electronic Components Feature And Application

eMetering
Lighting
Industrial networking
Alarm systems
White goods

Motor control
