PCA9536DR Texas Instrument Electronic Components

China PCA9536DR Texas Instrument Electronic Components Directly Supply. Kinglionski is a large-scale PCA9536DR Texas Instrument Electronic Components manufacturer and supplier in China. PCA9536DR belongs to 4-bit 2.3- to 5.5-V I2C/SMBus I/O expander with config registers of Texas Instruments(TI).The PCA9536 device is a 4-bit I/O expander for the I2C bus and is designed for 1.65-V to 5.5-V VCC operation. It provides general-purpose remote I/O expansion for most microcontroller families through the I2C interface. The PCA9536 consists of a configuration (input or output selection), Input Port, Output Port, and Polarity Inversion (active-high or active-low operation) registers. The device outputs (latched) have high-current drive capability for directly driving LEDs.

This 4-bit I/O expander for the two-line bidirectional bus (I2C) is designed for 2.3-V to 5.5-V VCC operation. The PCA9536 features 4-bit Configuration (input or output selection), Input Port, Output Port, and Polarity Inversion (active high or active low) registers.

The system controller resets the PCA9536 in the event of a timeout or other improper operation by utilizing the power-on reset feature, which puts the registers in their default state and initializes the I2C/ SMBus state machine. The device outputs (latched) have high-current drive capability for directly driving LEDs, but has low current consumption.
