Home > Products > Nexperia > PESD1CAN 215 Electronic Components
PESD1CAN 215 Electronic Components
  • PESD1CAN 215 Electronic ComponentsPESD1CAN 215 Electronic Components

PESD1CAN 215 Electronic Components

Kinglionski is the agent and distributor Nexperia of model PESD1CAN 215 Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

PESD1CAN in a small SOT23 (TO-236AB) Surface-Mounted Device (SMD) plastic package designed to protect two automotive Controller Area Network (CAN) bus lines from the damage caused by ElectroStatic Discharge (ESD) and other transients.


PESD1CAN 215 Electronic Components Features

Type

Main product features

PESD1CAN,215

Due to the integrated diode structure only one small SOT23 package is needed to protect two CAN bus lines

Max. peak pulse power: PPP = 200 W at tp = 8/20 µs

Low clamping voltage: VCL = 40 V at Ipp =1A

Ultra low leakage current: IRM< 1 nA


Product  Description

The PESD1CAN is designed for the protection of two automotive CAN bus lines from the damage caused by ESD and surge pulses. The device can be used for both, high-speed CAN bus and fault-tolerant CAN bus protection. The PESD1CAN provides a surge capability of up to 200 W per line for an 8/20 µs waveform.


Product Application

CAN bus protection

Automotive applications
