QS3VH257PAG Electronic Components
  • QS3VH257PAG Electronic ComponentsQS3VH257PAG Electronic Components

QS3VH257PAG Electronic Components

Kinglionski is the Chinese agents and distributors of Renesas electronic components model QS3VH257PAG Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The QS3VH257PAG Electronic Components Hot Switch Quad 2:1 multiplexer/demultiplexer is a high bandwidth bus switch.The QS3VH257PAG is characterized for operation from -40°C to +85°C.

The QS3VH257PAG Electronic Components has very low ON resistance, resulting in under 250ps propagation delay through the switch. The Select (S) input controls the data flow. The multiplexers/demultiplexers are enabled when the Enable (E) input is low. In the ON state, the switches can pass signals up to 5V. In the OFF state, the switches offer very high impedence at the terminals.

The combination of near-zero propagation delay, high OFF impedance, and over-voltage tolerance makes the QS3VH257PAG ideal for high performance communication applications.

Product Features

5V tolerant I/Os
Low RON - 4Ω typical
Flat RON characteristics over operating range
Rail-to-rail switching 0 - 5V
Bidirectional dataflow with near-zero delay: no added ground bounce
Excellent RON matching between channels
High bandwidth - up to 500MHz
LVTTL-compatible control Inputs
Undershoot Clamp Diodes on all switch and control Inputs
Low I/O capacitance, 4pF typical
Available in QSOP, SOIC, and TSSOP packages

Product Applications

Low distortion analog switch
Replaces mechanical relay
ATM 25/155 switching
