RAA2213204GNP HB0 Electronic Components
  • RAA2213204GNP HB0 Electronic ComponentsRAA2213204GNP HB0 Electronic Components

RAA2213204GNP HB0 Electronic Components

Kinglionski is the Chinese agents and distributors of Renesas electronic components model RAA2213204GNP HB0 Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

RAA2213204GNP HB0 Electronic Components belongs to 20A Smart Power Stage (SPS) with Integrated High Accuracy Current and Temperature Monitors.

The RAA221320 is a Smart Power Stage (SPS) compatible with the ISL68xxx/69xxx Digital Multiphase (DMP) controllers. The SPS has integrated high-accuracy current and temperature monitors that are fed back to the controller to complete a multiphase DC/DC system. These monitors simplify design and increase performance by eliminating the DCR sensing network and associated thermal compensation. An industry-leading thermally enhanced 4x5 PQFN package allows minimal overall PCB real estate.

The SPS features a 3.3V compatible tri-state PWM input that works together with the Renesas multiphase PWM controllers to provide a robust solution in abnormal operating conditions.The SPS also improves system performance and reliability with integrated fault protection of UVLO, shorted HFET, over-temperature, and overcurrent. An open-drain fault reporting pin simplifies the handshake between the SPS and controllers and can disable the controller during startup and fault conditions.

Product Features

Input range: +3.0V to +16V
Supports 20A DC current
3.3V compatible tri-state PWM input
Downslope current sensing
±3% accuracy current monitor (IMON) with REFIN input
8mV/°C temperature monitor with OT flag
Comprehensive fault protection for high system reliability
Fault reporting outputs (TMON, Fault#, and IMON)
Up to 1.5MHz switching frequency
Pb-free (RoHS compliant), 25 Ld 4x5 PQFN

Product Applications

High frequency and high efficiency VRM and VRD
Core, graphic, and memory regulators for microprocessors
High density VR for server, networking, and cloud computing
POL DC/DC converters and video gaming consoles
