SN7407DR Texas Instrument Electronic Components
  • SN7407DR Texas Instrument Electronic ComponentsSN7407DR Texas Instrument Electronic Components

SN7407DR Texas Instrument Electronic Components

You can rest assured to buy SN7407DR Texas Instrument Electronic Components from Kinglionski and we will offer you the best after-sale service and timely delivery. Kinglionski is the agent and distributor of Texas Instruments model SN7407DR, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

Wholesale low price SN7407DR Texas Instrument Electronic Components made in China. Kinglionski is a SN7407DR Texas Instrument Electronic Components manufacturer and supplier in China.  Texas Instruments(TI)is the world's largest manufacturer of digital signal processors (DSP) and analog circuit components, and has been a leading supplier of analog chips for many years.SN7407DR belongs to  6-ch, 4.75-V to 5.25-V bipolar buffers with open-collector outputs  of Texas Instruments(TI).

The SN74x7 is a high sink current capable open-collector buffer. This device is high-voltage tolerant on the output of up to 30 V on the SNx407 model and 15 V on the SNx417 model. The SN74x7 is also useful for converting TTL voltage
levels to MOS levels.

These TTL hex buffers and drivers feature highvoltage open-collector outputs for interfacing with high-level circuits (such as MOS) or for driving high current loads (such as lamps or relays), and also are characterized for use as buffers for driving TTL inputs.

These devices perform the Boolean function Y = A in positive logic. These circuits are completely compatible with most TTL families. Inputs are diode clamped to minimize transmission-line effects, which simplifies design. Typical power dissipation is 145 mW, and average propagation delay time is 14 ns.

Product Features


Main product features



Convert TTL Voltage Levels to MOS Levels

High Sink-Current Capability Design

Open-Collector Driver for Indicator Lamps

Inputs Fully Compatible With Most TTL Circuits

Product Application

Audio Docks: Portable
Blu-ray Disc® Players and Home Theaters
MP3 Players or Recorders
Personal Digital Assistants (PDAs)
Power: Telecom and Server AC or DC Supply: Single Controllers: Analog and Digital
Solid-State Drive (SSD): Client and Enterprise
TV: LCD, Digital, and High-Definition (HDTV)
Tablets: Enterprise
Video Analytics: Servers
Wireless Headsets, Keyboards, and Mice
