SN74AHC1G08QDBVRQ1 Texas Instrument Electronic Components

Hot Selling Low Price SN74AHC1G08QDBVRQ1 Texas Instrument Electronic Components. Texas Instruments(TI)is the world's largest manufacturer of digital signal processors (DSP) and analog circuit components, and has been a leading supplier of analog chips for many years.SN74AHC1G08QDBVRQ1 belongs toAutomotive single 2-input, 2-V to 5.5-V AND gate of Texas Instruments(TI).

Product Features

①Low Power Consumption, 20-µA Max ICC
②±8-mA Output Drive at 5 V
③Schmitt Trigger Action at All Inputs Makes the Circuit Tolerant for Slower Input Rise and Fall Time
④ ESD Protection Level Per AEC-Q100 Classification
− 2000-V (H2) Human-Body Model
− 200-V (M3) Machine Model
− 1000-V (C5) Charged-Device Model
⑤Qualified for Automotive Applications
⑥Operating Range of 2 V to 5.5 V

Product description/ordering information

The SN74AHC1G08 is a single 2-input positive-AND gate. The device performs the Boolean function Y = A B or Y = A + B in positive logic.

† For the most current package and ordering information, see the Package Option Addendum at the end of this
document, or see the TI web site at http://www.ti.com.
‡ Package drawings, thermal data, and symbolization are available at http://www.ti.com/packaging.
§ The actual top-side marking has one additional character that designates the wafer fab/assembly site

.
