SN74CBTLV3257RSVR Texas Instrument Electronic Components
  • SN74CBTLV3257RSVR Texas Instrument Electronic ComponentsSN74CBTLV3257RSVR Texas Instrument Electronic Components

SN74CBTLV3257RSVR Texas Instrument Electronic Components

Kinglionski as a professional high quality SN74CBTLV3257RSVR Texas Instrument Electronic Components manufacturer. Kinglionski is the agent and distributor of Texas Instruments model SN74CBTLV3257RSVR , focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

High quality SN74CBTLV3257RSVR Texas Instrument Electronic Components made in China. SN74CBTLV3257RSVR belongs to 3.3-V, 2:1 (SPDT), 4-channel analog switch with partial-power-down mode of Texas Instruments(TI).The SN74CBTLV3257 device is a 4-bit 1-of-2 high-speed FET multiplexer and demultiplexer.  The select (S) input controls the data flow.


The FET multiplexers and demultiplexers are disabled when the output-enable (OE) input is high. This device is fully specified for partial-power-down applications using Ioff. The Ioff feature ensures that damaging current will not backflow through the device when it is powered down. To ensure the high-impedance state during power up or power down, OE should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.


The SN74CBTLV3257 device is a 4-bit 1-of-2 highspeed FET multiplexer/demultiplexer. The select (S) input controls the data flow. This device is fully specified for partial-power-down applications using Ioff. The Ioff feature ensures that damaging current will not backflow through the device when it is powered down.


The device has isolation during power off. To ensure the high-impedance state during power up or power down, OE should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.


Product Features


Type

Main product features

SN74CBTLV3257RSVR

5-ΩSwitch Connection Between Two Ports

Rail-to-Rail Switching on Data I/O Ports

Ioff Supports Partial-Power-Down Mode Operation

Latch-Up Performance Exceeds 100 mA Per

JESD 78, Class II

Product Application

Internet of Things
Wireless Headphones
Television Set
4-Bit Bus Multiplexing and Demultiplexing
