TCA9617ADGKR Electronic Components
  • TCA9617ADGKR Electronic ComponentsTCA9617ADGKR Electronic Components

TCA9617ADGKR Electronic Components

Kinglionski is the agent and distributor of Texas Instruments model TCA9617ADGKR Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

TCA9617ADGKR Electronic Components belongs to 2-bit level-translating 1-MHz I2C/SMBus buffer/repeater.The TCA9617ADGKR is a BiCMOS dual bidirectional buffer intended for I²C bus and SMBus systems. As with the standard I 2C system, pullup resistors are required to provide the logic high levels on the buffered bus.


The TCA9617ADGKR has standard open-drain configuration of the I 2C bus. The size of these pullup resistors depends on the system, but each side of the repeater must have a pullup resistor. The device is designed to work with Standard mode, Fast mode and Fast Mode+ I 2C devices.


The TCA9617ADGKR is a BiCMOS dual bidirectional buffer intended for I²C bus and SMBus systems. It can provide bidirectional voltage-level translation (uptranslation and down-translation) between low voltages (down to 0.8 V) and higher voltages (2.2 V to 5.5 V) in mixed-mode applications. This device enables I 2C and similar bus systems to be extended, without degradation of performance even during level shifting.


Product Features

Type

Main product features

TCA9617ADGKR

Operating Supply Voltage Range of 0.8 V to 5.5 V on A-Side

Operating Supply Voltage Range of 2.2 V to 5.5 V on B-Side

Mixed-Mode Signal Operation

Lockup-Free Operation


Product Applications

Servers

Routers (Telecom Switching Equipment)

Industrial Equipment

Products With Many I 2C Slaves and/or Long PCB Traces
