TLV9024QPWRQ1 Texas Instrument Electronic Components

Kinglionski is one of the famous China TLV9024QPWRQ1 Texas Instrument Electronic Components manufacturers and suppliers. TLV9024QPWRQ1 belongs to Automotive, 5.5-V, low-voltage, high-performance, quad open-drain comparator with 120-ns delay of Texas Instruments(TI).The TLV902x-Q1 and TLV903x-Q1 devices are dual-channel, micro-power comparators with push-pull and open-drain outputs and low input offset voltage.

Operating down to 1.65 V while only consuming only 16 µA per channel, the TLV902x-Q1 and TLV903x-Q1 are ideally suited for portable, automotive and industrial applications. An internal power-on reset circuit ensures that the output remains in a known state during power-up and power-down while fail-safe inputs can tolerate input transients without damage or false outputs.

The TLV902x-Q1 and TLV903x-Q1 are a family of Automotive grade dual and quad channel comparators. This device family also includes a Power-on Reset (POR) feature that ensures the output is in a known state until the minimum supply voltage has been reached and a small time period passed before the output starts responding to the inputs. This prevents output transients during system power-up and powerdown.

These comparators also feature no output phase inversion with fault-tolerant inputs that can go up to 6-V without damage. The TLV902x-Q1 comparators have an open-drain output stage that can be pulled below or beyond the supply voltage, making it appropriate for low voltage logic and level translators.

The TLV903x-Q1 comparators have a push-pull output stage capable of sinking and sourcing milliamps of current when controlling an LED or driving a capacitive load such as a MOSFET gate. The TLV902x-Q1 and TLV903x-Q1 are specified for the Automotive temperature range of -40°C to +125°C and are available in a standard leaded and leadless packages.

Product Features

Type	Main product features
TLV9024QPWRQ1	Qualified for automotive applications
	AEC-Q100 qualified with the following results
	1.65 V to 5.5 V supply range
	Power-On Reset (POR) for known start-up

Product Application

Automotive
– HEV/EV and power train
– Infotainment and cluster
– Body control module
 Industrial
