TPS7B7701QPWPRQ1 Texas Instrument Electronic Components
  • TPS7B7701QPWPRQ1 Texas Instrument Electronic ComponentsTPS7B7701QPWPRQ1 Texas Instrument Electronic Components

TPS7B7701QPWPRQ1 Texas Instrument Electronic Components

Kinglionski is the agent and distributor of Texas Instruments model TPS7B7701QPWPRQ1, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

TPS7B7701QPWPRQ1:Low dropout voltage regulator  Automotive 300-mA, off-battery (40-V), adjustable antenna low-dropout voltage regulator 16-HTSSOP -40 to 125The TPS7B770x-Q1 family of devices feature a single- or dual-channel, high voltage LDO with a current-sense function.


These devices operate with a wide input-voltage range of 4.5 V to 40 V (45-V load dump protection). These devices also offers protection of antenna lines against electrostatic discharge (ESD) and from short-toground, short-to-battery, and thermal overstress. Device output voltage is adjustable from 1.5 V to 20 V through an external resistor divider. Alternatively, each channel can be configured as a switch.

These devices provide diagnostics through the current sense and error pins. To monitor the load current, a high-side current-sense circuitry provides a proportional analog output to the sensed load current. The accurate current sense allows detection of open, normal, and short-circuit conditions without the need for further calibration.

Product Features


Type

Main product features

TPS7B7701QPWPRQ1

Qualified for Automotive Applications

Single and Dual-Channel LDO With Current Sense and Adjustable Current-Limit

4.5-V to 40-V Wide Input Voltage Range, 45-V Load Dump

High Power-Supply Rejection Ratio: Typical 73 dB at 100 Hz



Product Application

Infotainment Active-Antenna Power Supplies
Surround-View Camera Power Supplies
High-Side Power Switch For Small-Current Applications
