TPS92515QDGQTQ1 Texas Instrument Electronic Components

The TPS92515QDGQTQ1 is an internal N-channel MOSFET (monolithic NFET) hysteric control, buck regulator. Hysteretic operation allows a high control bandwidth and is ideal for shunt FET and LED matrix applications (series LED switched network). The high-side differential current sense with low adjustable threshold voltage via a 10:1 divider, provides an excellent method for regulating output current while maintaining high system efficiency.

The TPS92515 family of devices are compact monolithic switching regulators integrating a low resistance N-Channel MOSFET. The devices are intended for high-brightness LED lighting applications where efficiency, high bandwidth, PWM and/or analog dimming and small size are important.

TPS92515QDGQTQ1 Texas Instrument Electronic Components Features

Type	Main product features
TPS92515QDGQTQ1	AEC-Q100 Grade 1 Qualified
	Integrated 290-mΩ (typ) Internal N-Channel FET
	Low Offset High-side Peak Current Comparator
	Constant Average Current, up to 2 A

Product Applications

Automotive Lighting: LED Switched Matrix AFS Headlamps, DRL, High/Low Beam, Fog, Rear, Turn Signal, Side Marker, Aftermarket Industrial Lighting: Factory Automation, Time of Flight (TOF), Appliances, Retail Illumination, Machine Vision and Inspection, Emergency, Exit and/or Safety Lighting, Medical Lighting, Stage and Area Lighting Agricultural, Marine, and Heavy Industry Lighting High Contrast Shunt FET Dimming
