FS32K144UAT0VLLT NXP Electronic Components

FS32K144UAT0VLLT：ARM microcontroller MCU S32K144 Arm Cortex-M4F, 112 MHz, 512 Kb Flash, CAN FD, FlexIO, CSEc security, LQFP100 - S32K MCUs for General Purpose.Functional operating conditions appear in the DC electrical characteristics. Absolute maximum ratings are stress ratings only, and functional operation at the maximum values is not guaranteed. See footnotes in the following table for specific conditions.

Stress beyond the listed maximum values may affect device reliability or cause permanent damage to the device.All the limits defined in the datasheet specification must be honored together and any violation to any one or more will not guarantee desired operation. Unless otherwise specified, all maximum and minimum values in the datasheet are across process, voltage, and temperature.

FS32K144UAT0VLLT NXP Electronic Components Features

Operating characteristics

–Voltage range: 2.7 V to 5.5 V

–Ambient temperature range: -40°C to 105°C for HSRUN mode, -40°C to 150°C for RUN mode

Arm™Cortex-M4F/M0+ core, 32-bit CPU

–Supports up to 112 MHz frequency (HSRUN mode) with 1.25 Dhrystone MIPS per MHz

–Arm Core based on the Armv7 Architecture and Thumb®-2 ISA

Human-machine interface (HMI)

–Up to 156 GPIO pins with interrupt functionality

–Non-Maskable Interrupt (NMI)
