MC33931EKR2 NXP Electronic Components

Kinglionski is the agent and distributor NXP electronic components of MC33931EKR2 NXP Electronic Components , focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The MC33931EKR2 is a monolithic H-bridge power IC in a robust thermally enhanced package. It is designed primarily for automotive electronic throttle control, but is applicable to any low voltage DC servo motor control application within the current and voltage limits stated in this specification.

The MC33931EKR2 H-bridge is able to control inductive loads with currents up to 5.0 A peak. RMS current capability is subject to the degree of heat sinking provided to the device package. Internal peak-current limiting (regulation) is activated at load currents above 6.5 A ± 1.5 A.

MC33931EKR2 NXP Electronic Components Features

Type	Main product features
MC33931EKR2	5.0 to 28 V continuous operation
	3.0 V and 5.0 V TTL / CMOS logic compatible inputs
	Overcurrent limiting (regulation) via internal constant-off-time PWM
	Temperature dependent current limit threshold reduction
