MC33SB0400ESR2 NXP Electronic Components

Kinglionski is the agent and distributor NXP electronic components of MC33SB0400ESR2 NXP Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The MC33SB0400ESR2 is an antilock brake controller designed for use in harsh motorcycle environments.The MC33SB0400ESR2 is a solution for ABS braking application, and powered by SMARTMOS technology.

It has four high-current low-side drivers for use with solenoid valves, two configurable wheel speed sense inputs capable of handling active sensors, and high-side gate drivers for controlling two external N-channel MOSFETs for use with a pump motor and master relay for solenoid coils. Along with this main functionality, the MC33SB0400ESR2 also has a warning lamp driver and a K-line transceiver.

The MC33SB0400ESR2 boosts an internal charge pump, allowing the high-side drivers to use inexpensive N-channel MOSFETs. The digital I/O pins can be configured for both 5.0 V and 3.3 V levels for easy connection to any microprocessor. The MC33SB0400ESR2 uses standard SPI protocol for communication.

MC33SB0400ESR2 NXP Electronic Components Features

Type	Main product features
MC33SB0400ESR2	Four PWMed valves driver
	High-side pre-driver for valves protection
	Dual vehicle speed outputs
	Pump motor pre-driver
