MKL43Z256VMP4 Electronic Components

Product Introduction

The MKL43Z256VMP4 Electronic Components is optimized for cost-sensitive and batterypowered applications requiring low-power USB connectivity and segment LCD.The product offers:

①Low power segment LCD up to 24x8 or 28x4

②USB FS 2.0 device without requiring an external crystal

③Embedded ROM with boot loader for flexible program upgrade

④High accuracy internal voltage and clock reference

⑤FlexIO to support any standard and customized serial peripheral emulation

⑥Down to 54uA/MHz in very low power run mode and 1.96uA in deep sleep mode (RAM + RTC retained)

Product Clocks

48MHz high accuracy (up to 0.5%) internal reference clock

8MHz/2MHz high accuracy (up to 3%) internal reference clock

1KHz reference clock active under all low-power modes (except VLLS0) 32–40KHz and 3–32MHz crystal oscillator

Product Packages

64 LQFP 10mm x 10mm, 0.5mm pitch, 1.6mm thickness

64 MAPBGA 5mm x 5mm, 0.5mm pitch, 1.23mm thickness

Security and Integrity

bit unique identification number per chip

Advanced flash security

AC electrical characteristics

Unless otherwise specified, propagation delays are measured from the 50% to the 50% point, and rise and fall times are measured at the 20% and 80% points, as shown in the following figure.
