SPC5642AF2MLU1 Electronic Components
  • SPC5642AF2MLU1 Electronic ComponentsSPC5642AF2MLU1 Electronic Components

SPC5642AF2MLU1 Electronic Components

Kinglionski is the Chinese agents and distributors of NXP semiconductor model SPC5642AF2MLU1 Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets. SPC5642AF2MLU1
NXP semiconductor(NXP) is a newly independent semiconductor company and the world's largest automotive semiconductor supplier. The SPC5642AF2MLU1 is an ultra reliable mpc564xa MCU for automotive and industrial engine management.
This document provides electrical specifications, pin assignments, and package diagrams for the MPC5642A series of microcontroller units (MCUs). It also describes the device features and highlights important electrical and physical characteristics. For functional characteristics, refer to the device reference manual.

Send Inquiry

Product Description

Product Description

Buy Discount SPC5642AF2MLU1 Electronic Components with Free Sample made in China. This microcontroller is a 32-bit system-on-chip (SoC) device intended for use in mid-range engine control and automotive transmission control applications. It is compatible with devices in Freescale’s MPC5600 family and offers performance and capabilities beyond the MPC5632M devices.


The microcontroller’s e200z4 host processor core is built on the Power Architecture® technology and designed specifically for embedded applications.The device has two levels of memory hierarchy consisting of 8 KB of instruction cache, backed by a 128 KB on-chip SRAM and a 2 MB internal flash memory. For development, the device includes a calibration bus that is accessible only when using the Freescale VertiCal Calibration System.


Product  Main Features

①e200z4 core

②Crossbar switch (XBAR)

③Enhanced direct memory access (eDMA)

④Interrupt controller (INTC)

⑤Memory protection unit (MPU)


Electrical characteristics

This section contains detailed information on power considerations, DC/AC electrical characteristics, and AC timing specifications for the MPC5642A series of MCUs. The electrical specifications are preliminary and are from previous designs, design simulations, or initial evaluation.


These specifications may not be fully tested or guaranteed at this early stage of the product life cycle, however for production silicon these specifications will be met. Finalized specifications will be published after complete characterization and device qualifications have been completed.


In the tables where the device logic provides signals with their respective timing characteristics, the symbol “CC” for Controller Characteristics is included in the Symbol column. In the tables where the external system must provide signals with their respective timing characteristics to the device, the symbol “SR” for System Requirement is included in the Symbol column.
