TJA1021TK NXP Electronic Components

Kinglionski is the agent and distributor NXP electronic components of TJA1021TK NXP Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The TJA1021TK is the interface between the Local Interconnect Network (LIN) master/slave protocol controller and the physical bus in a LIN. It is primarily intended for in-vehicle sub-networks using baud rates from 1 kBd up to 20 kBd (/20 variant) and is compliant with LIN 2.0, LIN 2.1, LIN 2.2, LIN 2.2A, SAE J2602 and ISO 17987-4:2016 (12 V). The TJA1021 is pin-to-pin compatible with the TJA1020 and MC33662(B).

The transmit data stream of the protocol controller at the transmit data input (TXD) is converted by the TJA1021 into a bus signal with optimized slew rate and wave shaping to minimize ElectroMagnetic Emission (EME). The LIN bus output pin is pulled HIGH via an internal termination resistor. For a master application, an external resistor in series with a diode should be connected between pin INH or pin VBAT and pin LIN. The receiver detects the data stream at the LIN bus input pin and transfers it via pin RXD to the microcontroller.

TJA1021TK NXP Electronic Components Features

Type	Main product features
TJA1021TK	LIN 2.x/ISO 17987-4:2016 (12 V)/SAE J2602 compliant
	Baud rate up to 20 kBd (/20 variant)
	Very low ElectroMagnetic Emission (EME)
	High ElectroMagnetic Immunity (EMI)
