TJA1051T/CM NXP Electronic Components

Kinglionski is the agent and distributor NXP electronic components of TJA1051T/CM NXP Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The TJA1051T/CM is a high-speed CAN transceiver that provides an interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus. The transceiver is designed for high-speed CAN applications in the automotive industry, providing differential transmit and receive capability to (a microcontroller with) a CAN protocol controller.

The TJA1051 belongs to the third generation of high-speed CAN transceivers from NXP Semiconductors, offering significant improvements over first- and second-generation devices such as the TJA1050.The TJA1051 implements the CAN physical layer as defined in ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5. This implementation enables reliable communication in the CAN FD fast phase at data rates up to 5 Mbit/s.

TJA1051T/CM NXP Electronic Components Features

Type	Main product features
TJA1051T/CM	ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 compliant
	Timing guaranteed for data rates up to 5 Mbit/s in the CAN FD fast phase
	Suitable for 12 V and 24 V systems
	AEC-Q100 qualified
