TJA1057GTK Electronic Components

Kinglionski is the Chinese agents and distributors of NXP semiconductor model TJA1057GTK TJA1057GTK Electronic Components, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets. The TJA1057GTK belongs to High-speed CAN transceiver of NXP .

Send Inquiry

Product Description

The TJA1057GTK Electronic Components is part of the Mantis family of high-speed CAN transceivers.The TJA1057 offers a feature set optimized for 12 V automotive applications, with significant improvements over first- and second-generation CAN transceivers from NXP, such as the TJA1050, and excellent ElectroMagnetic Compatibility (EMC) performance.

A VIO pin on the TJA1057GT(K)/3 variants allows for direct interfacing with 3.3 V and 5 V-supplied microcontrollers.The TJA1057 implements the CAN physical layer as defined in ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5.These features make the TJA1057 an excellent choice for HS-CAN networks that only require basic CAN functionality.

Features and benefits

2.1 General

①Fully ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 compliant

②Optimized for use in 12 V automotive systems

③EMC performance satisfies 'Hardware Requirements for LIN, CAN and FlexRay Interfaces in Automotive Applications’, Version 1.3, May 2012.

④VIO input on TJA1057x/3 variants allows for direct interfacing with 3 V to 5 V microcontrollers. Variants without a VIO pin can interface with 3.3 V and 5 V-supplied microcontrollers, provided the microcontroller I/Os are 5 V tolerant.⑤AEC-Q100 qualified

⑥Dark green product (halogen free and Restriction of Hazardous Substances (RoHS) compliant)

⑦Both VIO and non-VIO variants are available in SO8 and leadless HVSON8 (3.0 mm3.0 mm) packages; HVSON8 with improved Automated Optical Inspection (AOI) capability

2.2 Predictable and fail-safe behavior

Functional behavior predictable under all supply conditions

Transceiver disengages from bus when not powered (zero load)

Transmit Data (TXD) dominant time-out function

Internal biasing of TXD and S input pins

2.3 Protection

High ESD handling capability on the bus pins (8 kV IEC and HBM)

Bus pins protected against transients in automotive environments

Undervoltage detection on pins VCC and VIO

Thermally protected

2.4 TJA1057 CAN FD (applicable to all product variants except TJA1057T)

Timing guaranteed for data rates up to 5 Mbit/s
