STM32G070CBT6 Electronics
  • STM32G070CBT6 ElectronicsSTM32G070CBT6 Electronics

STM32G070CBT6 Electronics

STM32G070CBT6 Electronics belongs to Mainstream Value line, Arm Cortex-M0+ MCU with 128Kbytes of Flash memory, 36Kbytes RAM, 64 MHz CPU, 4x USART, timers, ADC, comm. I/F, 2-3.6V of ST

Send Inquiry

Product Description

Kinglionski STM32G070CBT6 Electronics  suppliers in China who can wholesale STM32G070CBT6. The mainstream microcontrollers are based on high-performance Arm® Cortex®-M0+ 32-bit RISC core operating at up to 64 MHz frequency. Offering a high level of integration, they are suitable for a wide range of applications in consumer, industrial and appliance domains and ready for the Internet of Things (IoT) solutions.

The devices incorporate a memory protection unit (MPU), high-speed embedded memories (128 Kbytes of Flash program memory with read protection, write protection, and 36 Kbytes of SRAM), DMA and an extensive range of system functions, enhanced I/Os and peripherals.

The devices offer standard communication interfaces (two I2Cs, two SPIs / one I2S, and four USARTs), one 12-bit ADC (2.5 MSps) with up to 19 channels, a low-power RTC, an advanced control PWM timer, five general-purpose 16-bit timers, two basic timers, two watchdog timers, and a SysTick timer.

The devices operate within ambient temperatures from -40 to 85°C. They can operate with supply voltages from 2.0 V to 3.6 V.

Optimized dynamic consumption combined with a comprehensive set of power-saving modes allows the design of low-power applications.
VBAT direct battery input allows keeping RTC and backup registers powered.

STM32G070CBT6 Electronics Parameter (Specification)

Core: Arm® 32-bit Cortex®-M0+ CPU, frequency up to 64 MHz
-40°C to 85°C operating temperature
128 Kbytes of Flash memory with protection
36 Kbytes of SRAM (32 Kbytes with HW parity check)
CRC calculation unit
Reset and power management
Voltage range: 2.0 V to 3.6 V

Power-on/Power-down reset (POR/PDR)
Low-power modes:Sleep, Stop, Standby
VBAT supply for RTC and backup registers
Clock management
4 to 48 MHz crystal oscillator
32 kHz crystal oscillator with calibration
Internal 16 MHz RC with PLL option
Internal 32 kHz RC oscillator (±5 %)

Up to 59 fast I/Os
All mappable on external interrupt vectors
Multiple 5 V-tolerant I/Os
7-channel DMA controller with flexible mapping
12-bit, 0.4 µs ADC (up to 16 ext. channels)
Up to 16-bit with hardware oversampling
Conversion range: 0 to 3.6V

11 timers: 16-bit for advanced motor control, five 16-bit general-purpose, two basic 16-bit, two watchdogs, SysTick timer
Calendar RTC with alarm and periodic wakeup from Stop/Standby
Communication interfaces
Two I2C-bus interfaces supporting Fast-mode Plus (1 Mbit/s) with extra current sink, one supporting SMBus/PMBus and wakeup from Stop mode

Four USARTs with master/slave synchronous SPI; two supporting ISO7816 interface, LIN, IrDA capability, auto baud rate detection and wakeup feature
Two SPIs (32 Mbit/s) with 4- to 16-bit programmable bitframe, one multiplexed with I2S interface
Development support: serial wire debug (SWD)
All packages ECOPACK 2 compliant

STM32G070CBT6 Electronics Feature And Application

Motor drive and application control
Medical equipment
Industrial applications: PLC, inverters, circuit breakers
Printers, and scanners
Alarm systems, video intercom, and HVAC

Home audio appliances
