L9369-TR STMicro Electronics

Kinglionski is the agent and distributor of L9369-TR STMicro Electronics, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The L9369-TR targets the specific application of electric parking braking, suitable for system configuration in cable-puller or Motor Gear Unit (MGU).

The cores are two H-bridge driver stages to drive 8 external FETs for the rear wheels brakes actuators. The stages are fully driven and configurable via SPI, also in PWM control mode and protected against overcurrent, with drainsource and gate-source voltages monitoring.

The set of the interfaces is completed by 4 GPIO (General Purpose I/O) pins and a button interface allows to manage specific customer requirements from Electronic parking braking (EPB) button console both in Normal and Sleep Mode.

L9369-TR STMicro Electronics Features

Type	Main product features
L9369-TR	AEC-Q100 qualified
	Functional safety concept for ISO26262 compliance
	4 High-side and Low-side gate pre-drivers for 8 external power NFETs
