STM32F302RET6 Electronics

STM32F302RET6 Electronics belongs to Mainstream Mixed signals MCUs Arm Cortex-M4 core with DSP and FPU, 512 Kbytes of Flash memory, 72 MHz CPU, MPU, 12-bit ADC 5 MSPS, PGA, comparators.The STM32F302RET6 is based on the high-performance ARM® Cortex®-M4 32-bit RISC core with FPU operating at a frequency of 72 MHz, and embedding a floating point unit (FPU), a memory protection unit (MPU) and an embedded trace macrocell (ETM).

The family incorporates high-speed embedded memories (512-Kbyte Flash memory, 64-Kbyte SRAM), a flexible memory controller (FSMC) for static memories (SRAM, PSRAM, NOR and NAND), and an extensive range of enhanced I/Os and peripherals connected to an AHB and two APB buses.

The STM32F302RET6 operates in the -40 to +85°C and -40 to +105°C temperature ranges from a 2.0 to 3.6 V power supply. A comprehensive set of power-saving mode allows the design of low-power applications. The STM32F302xD/E family offers devices in different packages ranging from 64 to 144 pins.

Product Features

Type	Main product features
STM32F302RET6	Core: ARM® Cortex®-M4 32-bit CPU with 72 MHz FPU, single-cycle multiplication and HW division, DSP instruction and MPU (memory protection unit)
	Operating conditions: –VDD, VDDA voltage range: 2.0 V to 3.6 V
	CRC calculation unit
	Interconnect matrix

Overview of main functions

ARM® Cortex®-M4 core with FPU with embedded Flash and
SRAM
Memory protection unit (MPU)
Embedded Flash memory
Embedded SRAM
Boot modes
Cyclic redundancy check (CRC)
