STM32F427VGT6 Electronics

STM32F427VGT6 Electronics belongs to High-performance advanced line, Arm Cortex-M4 core with DSP and FPU, 1 Mbyte of Flash memory, 180 MHz CPU, ART Accelerator, Chrom-ART Accelerator, FSMC.

Product Features

Type	Main product features
STM32F427VGT6	Core: Arm® 32-bit Cortex®-M4 CPU with FPU, Adaptive real-time accelerator (ART Accelerator™) allowing 0-wait state execution from Flash memory, frequency up to 180 MHz, MPU, 225 DMIPS/1.25 DMIPS/MHz (Dhrystone 2.1), and DSP instructions
	Memories：  –Up to 2 MB of Flash memory organized into two banks allowing read-while-write –Up to 256+4 KB of SRAM including 64-KB of CCM (core coupled memory) data RAM –Flexible external memory controller with up to 32-bit data bus: SRAM, PSRAM, SDRAM/LPSDR SDRAM, Compact Flash/NOR/NAND memories
	LCD parallel int erface, 8080/6800 modes

Product Description

The STM32F427VGT6 devices are based on the high-performance Arm® Cortex®-M4 32-bit RISC core operating at a frequency of up to 180 MHz. The Cortex-M4 core features a Floating point unit (FPU) single precision which supports all Arm® singleprecision data-processing instructions and data types. It also implements a full set of DSP instructions and a memory protection unit (MPU) which enhances application security.

The STM32F427VGT6 devices incorporate high-speed embedded memories (Flash memory up to 2 Mbyte, up to 256 Kbytes of SRAM), up to 4 Kbytes of backup SRAM, and an extensive range of enhanced I/Os and peripherals connected to two APB buses, two AHB buses and a 32-bit multi-AHB bus matrix.

These features make the STM32F427VGT6 microcontrollers suitable for a wide range of applications:
-Motor drive and application control
-Medical equipment
-Industrial applications: PLC, inverters, circuit breakers
- Printers, and scanners
- Alarm systems, video intercom, and HVAC
-Home audio appliances Figure 4 shows the general block diagram of the device family
