STM8S103K3T6C Electronics

STM8S103K3T6C Electronics belongs to Mainstream Access line 8-bit MCU with 8 Kbytes Flash, 16 MHz CPU, integrated EEPROM.

Product Features

Type	Main product features
STM8S103K3T6C	Core -16 MHz advanced STM8 core with Harvard architecture and 3-stage pipeline -Extended instruction set
	Memories -Program memory: 8 Kbyte Flash; data retention 20 years at 55°C after 10 kcycle -Data memory: 640 byte true data EEPROM; endurance 300 kcycle - RAM: 1 Kbyte
	Interrupt management - Nested interrupt controller with 32 interrupts -Up to 27 external interrupts on 6 vectors

Product Description

The STM8S103K3T6C access line 8-bit microcontrollers offer 8 Kbyte Flash program memory, plus integrated true data EEPROM. The STM8S microcontroller family reference manual (RM0016) refers to devices in this family as low-density. They provide the following benefits: performance, robustness, and reduced system cost.

Device performance and robustness are ensured by advanced core and peripherals made in a state-of-the art technology, a 16 MHz clock frequency, robust I/Os, independent watchdogs with separate clock source, and a clock security system. The system cost is reduced thanks to an integrated true data EEPROM for up to 300 k write/erase cycles and a high system integration level with internal clock oscillators, watchdog and brown-out reset.
