VN5160STR-E Electronics
  • VN5160STR-E ElectronicsVN5160STR-E Electronics

VN5160STR-E Electronics

Kinglionski is the agent and distributor of STMicroelectronics model VN5160STR-E Electronics, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

VN5160STR-E Electronics belongs to Single channel high side drive for automotive applications.The VN5160S-E is a monolithic device made using STMicroelectronics VIPower M0-5 technology. It is intended for driving resistive or inductive loads with one side connected to ground. Active VCC voltage clamp protects the device against low energy spikes.


Product Features

Type

Main product features

VN5160STR-E

Main

–Inrush current active management by power limitation

–Very low stand-by current

Diagnostic Functions

–Open drain status output

–On-state open load detection

 Protection

–Undervoltage shutdown

–Overvoltage clamp



Product Description

The VN5160STR-E device detects open load condition both in on and offstate, when STAT_DIS is left open or driven low. Output shorted to VCC is detected in the off-state. When STAT_DIS is driven high, STATUS is in a high impedance condition. Output current limitation protects the device in overload condition.



In case of long duration overload, the device limits the dissipated power to safe level up to thermal shutdown intervention. Thermal shutdown with automatic restart allows the device to recover normal operation as soon as fault condition disappears.



Product Application

All types of resistive, inductive and capacitive loads
