VN5E025AJTR-E Electronics

VN5E025AJTR-E Electronics belongs to Single channel high side driver with analog current sense for automotive applications. The VN5E050J-E is a single channel high-side driver manufactured in the ST proprietary VIPower M0-5 technology and housed in the tiny PowerSSO-12 package.

Product Features

Type	Main product features
VN5E025AJTR-E	General –Inrush current active management by power limitation –3.0V CMOS compatible inputs
	Diagnostic functions –Open Drain status output –Off-state open load detection
	Protections –Undervoltage shut-down –Self-limiting of fast thermal transients

Product Description

The VN5E050J-E is designed to drive automotive grounded loads delivering protection, diagnostics and easy 3V and 5V CMOS-compatible interface with any microcontroller.

The device integrates advanced protective functions such as load current limitation, inrush and overload active management by power limitation, over-temperature shut-off with autorestart and over-voltage active clamp.

A dedicated active low digital status pin is associated with every output channel in order to provide Enhanced diagnostic functions including fast detection of overload and short-circuit to ground, over-temperature indication, short-circuit to VCC diagnosis and ON & OFF state open-load detection.

The diagnostic feedback of the whole device can be disabled by pulling the STAT_DIS pin up, thus allowing wired-ORing with other similar devices.

Product Application

All types of resistive, inductive and capacitive loads.
