VN5E160ASTR-E STMicro Electronics

Kinglionski is the agent and distributor of VN5E160ASTR-E STMicro Electronics, focusing on the foreign trade of electronic components for 12 years. It only makes new and original packaging, with reasonable price and high quality, and serves most of the European and American markets.

Send Inquiry

Product Description

The VN5E160ASTR-E is a single-channel high-side driver manufactured in the ST proprietary VIPower™ M0-5 technology and housed in the tiny SO-8 package. The VN5E160AS-E is designed to drive 12 V automotive grounded loads delivering protection, diagnostics and easy 3 V and 5 V CMOS compatible interface with any microcontroller.

VN5E160ASTR-E STMicro Electronics Features

Type	Main product features
VN5E160ASTR-E	General：– Inrush current active management by power limitation
	Diagnostic functions：– Proportional load current sense
	Protections：– Undervoltage shutdown

Product Description

The VN5E160ASTR-E device integrates advanced protective functions such as load current limitation, inrush and overload active management by power limitation, overtemperature shut-off with auto-restart and overvoltage active clamp. A dedicated analog current sense pin is associated with every output channel in order to provide ehnanced diagnostic functions including fast detection of overload and short-circuit to ground through power limitation indication, overtemperature indication, short-circuit to VCC diagnosis and ON & OFF state open-load detection.
